Add property text to PCB

This interactive app helps speed up documentation production and provides support for variants

description of the appSimplify documentation process tasks

This tool will enable you to add the text of the properties for each component on a selected user layer. Text can be placed on different layers depending on the relevant Variant.

benefits of the appTop Benefits for the Add Property Text to PCB app

  1. Speed up documentation production
  2. Support for Variants
  3. Interactive property / layer association

app explainer videoDemo

This video demonstrates the Add Property Text to PCB app designed by a 3rd party for eCADSTAR’s PCB Editor.

User Guide eCADSTAR appAdd Property Text to PCB App User Guide

Learn how to install and run the app to get you up to speed in no time at all.

Download Now
Apps are provided and supported by 3rd parties, they are enhancing the eCADSTAR experience.

Created by:

Zuken Italy





Get the App for FREE

Please complete the form below and we will send you an email with the link to download the application.

Additional Information

Updated
February 7th 2021
Version no.
1.0
