NICHT VERBUNDENE PADS UND VIAS IN INNENLAGEN
In diesem Video wollen wir ansehen, wie eCADSTAR-nicht verbundener Pads auf Innenlagen behandelt.
Menu
Werfen wir einen Blick darauf wie eCADSTAR mit „non functional lands“ umgeht
Wenn Sie mit dem Ausdruck „none functional lands“ nicht vertraut sind: so bezeichnen wir Pads auf internen Schichten, die keine Verbindung haben. Die Pads auf Lagen sindalso unnötige Merkmale, die eCADSTAR erkannt und entfernt werden.
