UNCONNECTED INNER-LAYER PADS OR VIAS
In this video we are going to focus on eCADSTAR flexibility suppress unconnected inner-layer pads.
Menu
Let’s focus on eCADSTAR’s flexibility regarding none functional lands
If you’re not familiar with the phrase none functional lands all we are referring to are pads on internal layers that have no connection. Optimizing manufacturing by removing unconnected inner-layer pads. So the pads on layers where no connection exists are unnecessary features.
