3D PCB Design Software

A modern PCB design platform built to utilise the latest technology advancements

NATIVE 64-BIT HIGH PERFORMANCE

eCADSTAR Library Editor, Schematic Editor and PCB Editor are native 64-bit. Fast, efficient memory management, calculations and algorithms mean your EDA keeps pace with your designers’ creativity.

64-bit-300x300

2d3d-laptop-1024x586

NATIVE 3D ENVIRONMENT WITH DIRECT 3D TECHNOLOGY FOR MAXIMUM PERFORMANCE

Once you can work in 3D, you’ll wonder how you lived without it. In a 3D world you need the full picture.

Change the view from 2D to 3D with realistic part models. Where will those decoupling caps fit? Not there? OK, flip the board over. There’s room under those SMD pads, but those caps are still too big. Let’s search online. Yes, those 0201 caps are the right spec. and price. Download to library, place in schematic, forward-annotate to PCB.

Now let’s see. Yes, they fit! Just rotate the PCB to check. Perfect!

MULTICORE/MULTITHREAD OPERATION

With a smart mix of multiprocessing and multithreading, eCADSTAR gets results faster – taking full advantage of your multicore CPU.

multi-core
