Speed and precision for manual routing
CADSTAR PCB Placement and Routing Tools
CADSTAR Place and Route Editor
With a mix of manual, auto-interactive and automatic tools for PCB placement and routing, the CADSTAR Place and Route Editor 2000 has been optimized for performance, quality and manufacturability to meet today’s advanced technology design challenges.
True 45-degree routing algorithm: routes effortlessly through even the densest designs
Pushing existing routes and vias aside, while always obeying design rules
Layout optimization to minimize overall track length, reduce number of vias and improve manufacturability
CADSTAR Place and Route Editor key features
Find out more about our CADSTAR Place and Route Editor
The advanced Activ-45 router provides the ultimate in speed and precision for manual routing, offering single-click ‘follow me’ routing with automatic completion, using push-aside, spring-back and segment break options to tackle even the most complex layout challenges.
The Activ-45 router makes space for itself by pushing existing routes and vias aside, while always obeying design rules. Where necessary, it will flip existing routes over pins and pads to create even more space, such as when creating a BGA fan-out. At any point before completing the route, if the cursor is moved back towards the starting point, the routes will spring-back to their original position.
Prior to routing, power pins can be intelligently connected to full or partial planes, and the fanout router used to create intelligent breakout patterns for high pin-count SMT devices, using geometric or spiral via patterns to simplify routing on inner layers.
Optimization of the layout to minimize overall track length, reduce the number of vias and improve manufacturability. Testpoints for clamshell fixtures or flying-probe testers can be allocated to existing design features if allowed or inserted as user-defined testpoint elements.
CADSTAR's routing capability can be extended to meet your specific design requirements
With enhanced Topology support, CADSTAR Constraint Browser provides a fast and effective way for design engineers to add rules and net constraints to the Schematic at the initial design phase.
The Dragon Routing Platform moves away from traditional settings-based autorouting to an alternative methodology that combines artificial intelligence with a strategy-driven approach to solve your routing requirements.
For High-speed designs, Place & Route Editor XR 5000HS obeys a wide range of fast circuit rules including min/max length, skew, delay and crosstalk limits to meet tight timing and noise margins. Manual and automatic editing tools enable nets to be tuned precisely for track length or flight-time to achieve optimum timing characteristics.
The Rules-by-Area package is a powerful extension to the CADSTAR P.R.Editor XR 2000 tool. It enhances Zuken’s routing technology by allowing the association of different design rules to different areas of the design. With Rules-by-Area, tracks can be reduced in width according to the rules defined by the area they are routed through. Rules also include via sizes and the use of blind or buried via technology.
CADSTAR Place and Route Editor
The matrix describes the features associated with each CADSTAR Place and Route Editor bundle.
For PCB designers and engineers, autorouting can be one way of saving time and money, whilst coping with the increase in complexity.
The Rules-by-Area package is a powerful extension to the CADSTAR P.R.Editor XR 2000 tool-set that enhances Zuken’s routing technology by allowing the association of different design rules to different areas of the design.
As design constraints increase in complexity, CADSTAR Constraint Browser simplifies constraint management by providing a fast and effective method to enter the most complex of rules.
Easy to learn and fast to use, CADSTAR delivers high performance PCB layout to your desktop.
