Differential Pair Configuration
In this video we are going to look at the basic configuration and routing of differential pairs in eCADSTAR.
Menu
Let’s focus on differential pair configuration
First of all, we open our constraint browser, then I click on the create multiple differential pairs icon. This scans both Enets and net lists for matching names with a differentiating suffix which you can also customize…
