Differential Pair Configuration

Configurazione Della Coppia Differenziale

In questo video vedremo la configurazione di base e il routing delle coppie differenziali in eCADSTAR.
Menu

Concentriamoci sulla configurazione della coppia differenziale

Prima di tutto, apriamo il nostro browser dei vincoli, poi clicco sull’icona di creazione di coppie differenziali multiple. Questo analizza sia Enets che le liste di net alla ricerca di nomi corrispondenti con un suffisso differenziale che si può anche personalizzare…
